Property class. More...

Public Member Functions
mlt_color	mlt_property_anim_get_color (mlt_property self, double fps, mlt_locale_t locale, int position, int length)
	Get a color at a frame position. More...

double	mlt_property_anim_get_double (mlt_property self, double fps, mlt_locale_t locale, int position, int length)
	Get the real number at a frame position. More...

int	mlt_property_anim_get_int (mlt_property self, double fps, mlt_locale_t locale, int position, int length)
	Get the property as an integer number at a frame position. More...

mlt_rect	mlt_property_anim_get_rect (mlt_property self, double fps, mlt_locale_t locale, int position, int length)
	Get a rectangle at a frame position. More...

char *	mlt_property_anim_get_string (mlt_property self, double fps, mlt_locale_t locale, int position, int length)
	Get the string at certain a frame position. More...

int	mlt_property_anim_set_color (mlt_property self, mlt_color value, double fps, mlt_locale_t locale, int position, int length, mlt_keyframe_type keyframe_type)
	Set a property animation keyframe to a color. More...

int	mlt_property_anim_set_double (mlt_property self, double value, double fps, mlt_locale_t locale, int position, int length, mlt_keyframe_type keyframe_type)
	Set a property animation keyframe to a real number. More...

int	mlt_property_anim_set_int (mlt_property self, int value, double fps, mlt_locale_t locale, int position, int length, mlt_keyframe_type keyframe_type)
	Set a property animation keyframe to an integer value. More...

int	mlt_property_anim_set_rect (mlt_property self, mlt_rect value, double fps, mlt_locale_t locale, int position, int length, mlt_keyframe_type keyframe_type)
	Set a property animation keyframe to a rectangle. More...

int	mlt_property_anim_set_string (mlt_property self, const char *value, double fps, mlt_locale_t locale, int position, int length)
	Set a property animation keyframe to a string. More...

void	mlt_property_clear (mlt_property self)
	Clear (0/null) a property. More...

void	mlt_property_close (mlt_property self)
	Destroy a property and free all related resources. More...

mlt_animation	mlt_property_get_animation (mlt_property self)
	Get an object's animation object. More...

mlt_color	mlt_property_get_color (mlt_property self, double fps, mlt_locale_t locale)
	Get the property as a color. More...

void *	mlt_property_get_data (mlt_property self, int *length)
	Get the binary data from a property. More...

double	mlt_property_get_double (mlt_property self, double fps, mlt_locale_t locale)
	Get the property as a floating point. More...

int	mlt_property_get_int (mlt_property self, double fps, mlt_locale_t locale)
	Get the property as an integer. More...

int64_t	mlt_property_get_int64 (mlt_property self)
	Get the property as a signed integer. More...

mlt_position	mlt_property_get_position (mlt_property self, double fps, mlt_locale_t locale)
	Get the property as a position. More...

mlt_properties	mlt_property_get_properties (mlt_property self)
	Get a nested properties object. More...

mlt_rect	mlt_property_get_rect (mlt_property self, mlt_locale_t locale)
	Get the property as a rectangle. More...

char *	mlt_property_get_string (mlt_property self)
	Get the property as a string. More...

char *	mlt_property_get_string_l (mlt_property self, mlt_locale_t locale)
	Get the property as a string (with locale). More...

char *	mlt_property_get_string_l_tf (mlt_property self, mlt_locale_t locale, mlt_time_format time_format)
	Get the property as a string (with locale and time format). More...

char *	mlt_property_get_string_tf (mlt_property self, mlt_time_format time_format)
	Get the property as a string (with time format). More...

char *	mlt_property_get_time (mlt_property self, mlt_time_format format, double fps, mlt_locale_t locale)
	Get the property as a time string. More...

mlt_property	mlt_property_init ()
	Construct a property and initialize it. More...

int	mlt_property_interpolate (mlt_property self, mlt_property p[], double progress, double fps, mlt_locale_t locale, mlt_keyframe_type interp)
	Interpolate a new property value given a set of other properties. More...

int	mlt_property_is_anim (mlt_property self)
	Check if a property is animated. More...

int	mlt_property_is_clear (mlt_property self)
	Check if a property is cleared. More...

int	mlt_property_is_color (mlt_property self)
	Check if a property is a color. More...

int	mlt_property_is_numeric (mlt_property self, mlt_locale_t locale)
	Determine if the property holds a numeric or numeric string value. More...

int	mlt_property_is_rect (mlt_property self)
	Check if a property is a rect. More...

void	mlt_property_pass (mlt_property self, mlt_property that)
	Copy a property. More...

int	mlt_property_set_color (mlt_property self, mlt_color value)
	Set the property to a color value. More...

int	mlt_property_set_data (mlt_property self, void *value, int length, mlt_destructor destructor, mlt_serialiser serialiser)
	Set a property to an opaque binary value. More...

int	mlt_property_set_double (mlt_property self, double value)
	Set the property to a floating point value. More...

int	mlt_property_set_int (mlt_property self, int value)
	Set the property to an integer value. More...

int	mlt_property_set_int64 (mlt_property self, int64_t value)
	Set the property to a 64-bit integer value. More...

int	mlt_property_set_position (mlt_property self, mlt_position value)
	Set the property to a position value. More...

int	mlt_property_set_properties (mlt_property self, mlt_properties properties)
	Set a nested properties object. More...

int	mlt_property_set_rect (mlt_property self, mlt_rect value)
	Set a property to a mlt_rect rectangle. More...

int	mlt_property_set_string (mlt_property self, const char *value)
	Set the property to a string value. More...

Data Fields
mlt_animation	animation

void *	data
	Generic type handling. More...

mlt_destructor	destructor

int	length

pthread_mutex_t	mutex

double	prop_double

int	prop_int
	Atomic type handling. More...

int64_t	prop_int64

mlt_position	prop_position

char *	prop_string
	String handling. More...

mlt_properties	properties

mlt_serialiser	serialiser

mlt_property_type	types
	Stores a bit pattern of types available for this property. More...

Private Member Functions
static double	catmull_rom_interpolate (double y0, double y1, double y2, double y3, double t)
	A smooth spline interpolation for animation. More...

static void	clear_property (mlt_property self)
	Clear (0/null) a property. More...

static double	linear_interpolate (double y1, double y2, double t)
	A linear interpolation function for animation. More...

static double	mlt_property_atof (mlt_property self, double fps, mlt_locale_t locale)
	Convert a string to a floating point number. More...

static int	mlt_property_atoi (mlt_property self, double fps, mlt_locale_t locale)
	Convert a string to an integer. More...

static int64_t	mlt_property_atoll (const char *value)
	Convert a string to a 64-bit integer. More...

static void	refresh_animation (mlt_property self, double fps, mlt_locale_t locale, int length)
	Create a new animation or refresh an existing one. More...

static char *	serialise_mlt_rect (mlt_rect *rect, int length)
	Convert a rectangle value into a string. More...

static void	time_clock_from_frames (int frames, double fps, char *s)
	Convert frame count to a SMIL clock value string. More...

static int	time_clock_to_frames (mlt_property self, const char *s, double fps, mlt_locale_t locale)
	Parse a SMIL clock value. More...

static int	time_code_to_frames (mlt_property self, const char *s, double fps)
	Parse a SMPTE timecode string. More...

static void	time_smpte_from_frames (int frames, double fps, char *s, int drop)
	Convert frame count to a SMPTE timecode string. More...

Detailed Description

Property class.

A property is like a variant or dynamic type. They are used for many things in MLT, but in particular they are the parameter mechanism for the plugins.

Member Function Documentation

◆ catmull_rom_interpolate()

static double catmull_rom_interpolate	(	double	y0,
		double	y1,
		double	y2,
		double	y3,
		double	t
	)

inlineprivate

A smooth spline interpolation for animation.

Deprecated:: For non-closed curves, you need to also supply the tangent vector at the first and last control point. This is commonly done: T(P[0]) = P[1] - P[0] and T(P[n]) = P[n] - P[n-1].

◆ clear_property()

static void clear_property ( mlt_property self )

private

Clear (0/null) a property.

Frees up any associated resources in the process.

Parameters

self	a property

◆ linear_interpolate()

static double linear_interpolate	(	double	y1,
		double	y2,
		double	t
	)

inlineprivate

A linear interpolation function for animation.

Deprecated:

◆ mlt_property_anim_get_color()

mlt_color mlt_property_anim_get_color	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length
	)

Get a color at a frame position.

Parameters

self	a property
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

Returns: the color

◆ mlt_property_anim_get_double()

double mlt_property_anim_get_double	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length
	)

Get the real number at a frame position.

Parameters

self	a property
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

Returns: the real number

◆ mlt_property_anim_get_int()

int mlt_property_anim_get_int	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length
	)

Get the property as an integer number at a frame position.

Parameters

self	a property
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

Returns: an integer value

◆ mlt_property_anim_get_rect()

mlt_rect mlt_property_anim_get_rect	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length
	)

Get a rectangle at a frame position.

Parameters

self	a property
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

Returns: the rectangle

◆ mlt_property_anim_get_string()

char * mlt_property_anim_get_string	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length
	)

Get the string at certain a frame position.

Parameters

self	a property
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

Returns: the string representation of the property or NULL if failed

◆ mlt_property_anim_set_color()

int mlt_property_anim_set_color	(	mlt_property	self,
		mlt_color	value,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length,
		mlt_keyframe_type	keyframe_type
	)

Set a property animation keyframe to a color.

Parameters

self	a property
value	a color
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that
keyframe_type	the interpolation method for this keyframe

Returns: false if successful, true to indicate error

◆ mlt_property_anim_set_double()

int mlt_property_anim_set_double	(	mlt_property	self,
		double	value,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length,
		mlt_keyframe_type	keyframe_type
	)

Set a property animation keyframe to a real number.

Parameters

self	a property
value	a double precision floating point value
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that
keyframe_type	the interpolation method for this keyframe

Returns: false if successful, true to indicate error

◆ mlt_property_anim_set_int()

int mlt_property_anim_set_int	(	mlt_property	self,
		int	value,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length,
		mlt_keyframe_type	keyframe_type
	)

Set a property animation keyframe to an integer value.

Parameters

self	a property
value	an integer
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that
keyframe_type	the interpolation method for this keyframe

Returns: false if successful, true to indicate error

◆ mlt_property_anim_set_rect()

int mlt_property_anim_set_rect	(	mlt_property	self,
		mlt_rect	value,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length,
		mlt_keyframe_type	keyframe_type
	)

Set a property animation keyframe to a rectangle.

Parameters

self	a property
value	a rectangle
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that
keyframe_type	the interpolation method for this keyframe

Returns: false if successful, true to indicate error

◆ mlt_property_anim_set_string()

int mlt_property_anim_set_string	(	mlt_property	self,
		const char *	value,
		double	fps,
		mlt_locale_t	locale,
		int	position,
		int	length
	)

Set a property animation keyframe to a string.

Strings only support discrete animation. Do not use this to set a property's animation string that contains a semicolon-delimited set of values; use mlt_property_set() for that.

Parameters

self	a property
value	a string
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
position	the frame number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

Returns: false if successful, true to indicate error

◆ mlt_property_atof()

static double mlt_property_atof	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale
	)

private

Convert a string to a floating point number.

If the string contains a colon it is interpreted as a time value. If it also contains a period or comma character, the string is parsed as a clock value: HH:MM:SS. Otherwise, the time value is parsed as a SMPTE timecode: HH:MM:SS:FF. If the numeric string ends with '' then the value is divided by 100 to convert it into a ratio.

Parameters

self	a property
fps	frames per second, used when converting from time value
locale	the locale to use when converting from time clock value

Returns: the resultant real number

◆ mlt_property_atoi()

static int mlt_property_atoi	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale
	)

private

Convert a string to an integer.

The string must begin with '0x' to be interpreted as hexadecimal. Otherwise, it is interpreted as base 10.

If the string begins with '#' it is interpreted as a hexadecimal color value in the form RRGGBB or AARRGGBB. Color values that begin with '0x' are always in the form RRGGBBAA where the alpha components are not optional. Applications and services should expect the binary color value in bytes to be in the following order: RGBA. This means they will have to cast the int to an unsigned int. This is especially important when they need to shift right to obtain RGB without alpha in order to make it do a logical instead of arithmetic shift.

If the string contains a colon it is interpreted as a time value. If it also contains a period or comma character, the string is parsed as a clock value: HH:MM:SS. Otherwise, the time value is parsed as a SMPTE timecode: HH:MM:SS:FF.

Parameters

self	a property
fps	frames per second, used when converting from time value
locale	the locale to use when converting from time clock value

Returns: the resultant integer

◆ mlt_property_atoll()

static int64_t mlt_property_atoll ( const char * value )

inlineprivate

Convert a string to a 64-bit integer.

If the string begins with '0x' it is interpreted as a hexadecimal value.

Parameters

value a string

Returns: a 64-bit integer

◆ mlt_property_clear()

void mlt_property_clear ( mlt_property self )

Clear (0/null) a property.

Frees up any associated resources in the process.

Parameters

self	a property

◆ mlt_property_close()

void mlt_property_close ( mlt_property self )

Destroy a property and free all related resources.

Parameters

self	a property

◆ mlt_property_get_animation()

mlt_animation mlt_property_get_animation ( mlt_property self )

Get an object's animation object.

You might need to call another mlt_property_anim_ function to actually construct the animation, as this is a simple accessor function.

Parameters

self	a property

Returns: the animation object or NULL if there is no animation

◆ mlt_property_get_color()

mlt_color mlt_property_get_color	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale
	)

Get the property as a color.

Parameters

self	a property
fps	frames per second, used when converting from time value
locale	the locale to use for when converting from a string

Returns: a color value

◆ mlt_property_get_data()

void * mlt_property_get_data	(	mlt_property	self,
		int *	length
	)

Get the binary data from a property.

This only works if you previously put binary data into the property. This does not return a copy of the data; it returns a pointer to it. If you supplied a destructor function when setting the binary data, the destructor is used when the Property is closed to free the memory. Therefore, only free the returned pointer if you did not supply a destructor function.

Parameters

	self	a property
[out]	length	the size of the binary object in bytes (optional)

Returns: an opaque data pointer or NULL if not available

◆ mlt_property_get_double()

double mlt_property_get_double	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale
	)

Get the property as a floating point.

Parameters

self	a property
fps	frames per second, used when converting from time value
locale	the locale to use for this conversion

Returns: a floating point value

◆ mlt_property_get_int()

int mlt_property_get_int	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale
	)

Get the property as an integer.

Parameters

self	a property
fps	frames per second, used when converting from time value
locale	the locale to use when converting from time clock value

Returns: an integer value

◆ mlt_property_get_int64()

int64_t mlt_property_get_int64 ( mlt_property self )

Get the property as a signed integer.

Parameters

self	a property

Returns: a 64-bit integer

◆ mlt_property_get_position()

mlt_position mlt_property_get_position	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale
	)

Get the property as a position.

A position is an offset time in terms of frame units.

Parameters

self	a property
fps	frames per second, used when converting from time value
locale	the locale to use when converting from time clock value

Returns: the position in frames

◆ mlt_property_get_properties()

mlt_properties mlt_property_get_properties ( mlt_property self )

Get a nested properties object.

Parameters

self	a property

Returns: the nested properties list

◆ mlt_property_get_rect()

mlt_rect mlt_property_get_rect	(	mlt_property	self,
		mlt_locale_t	locale
	)

Get the property as a rectangle.

You can use any non-numeric character(s) as a field delimiter. If the number has a '' immediately following it, the number is divided by 100 to convert it into a real number.

Parameters

self	a property
locale	the locale to use for when converting from a string

Returns: a rectangle value

◆ mlt_property_get_string()

char * mlt_property_get_string ( mlt_property self )

Get the property as a string.

The caller is not responsible for deallocating the returned string! The string is deallocated when the Property is closed. This tries its hardest to convert the property to string including using a serialization function for binary data, if supplied.

Parameters

self	a property

Returns: a string representation of the property or NULL if failed

◆ mlt_property_get_string_l()

char * mlt_property_get_string_l	(	mlt_property	self,
		mlt_locale_t	locale
	)

Get the property as a string (with locale).

The caller is not responsible for deallocating the returned string! The string is deallocated when the Property is closed. This tries its hardest to convert the property to string including using a serialization function for binary data, if supplied.

Parameters

self	a property
locale	the locale to use for this conversion

Returns: a string representation of the property or NULL if failed

◆ mlt_property_get_string_l_tf()

char * mlt_property_get_string_l_tf	(	mlt_property	self,
		mlt_locale_t	locale,
		mlt_time_format	time_format
	)

Get the property as a string (with locale and time format).

The caller is not responsible for deallocating the returned string! The string is deallocated when the Property is closed. This tries its hardest to convert the property to string including using a serialization function for binary data, if supplied.

Parameters

self	a property
locale	the locale to use for this conversion
time_format	the time format to use for animation

Returns: a string representation of the property or NULL if failed

◆ mlt_property_get_string_tf()

char * mlt_property_get_string_tf	(	mlt_property	self,
		mlt_time_format	time_format
	)

Get the property as a string (with time format).

The caller is not responsible for deallocating the returned string! The string is deallocated when the Property is closed. This tries its hardest to convert the property to string including using a serialization function for binary data, if supplied.

Parameters

self	a property
time_format	the time format to use for animation

Returns: a string representation of the property or NULL if failed

◆ mlt_property_get_time()

char * mlt_property_get_time	(	mlt_property	self,
		mlt_time_format	format,
		double	fps,
		mlt_locale_t	locale
	)

Get the property as a time string.

The time value can be either a SMPTE timecode or SMIL clock value. The caller is not responsible for deallocating the returned string! The string is deallocated when the property is closed.

Parameters

self	a property
format	the time format that you want
fps	frames per second
locale	the locale to use for this conversion

Returns: a string representation of the property or NULL if failed

◆ mlt_property_init()

mlt_property mlt_property_init ( )

Construct a property and initialize it.

◆ mlt_property_interpolate()

int mlt_property_interpolate	(	mlt_property	self,
		mlt_property	p[],
		double	progress,
		double	fps,
		mlt_locale_t	locale,
		mlt_keyframe_type	interp
	)

Interpolate a new property value given a set of other properties.

Deprecated:

Parameters

self	the property onto which to set the computed value
p	an array of at least 1 value in p[1] if `interp` is discrete, 2 values in p[1] and p[2] if `interp` is linear, or 4 values in p[0] - p[3] if `interp` is smooth
progress	a ratio in the range [0, 1] to indicate how far between p[1] and p[2]
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
interp	the interpolation method to use

Returns: true if there was an error

◆ mlt_property_is_anim()

int mlt_property_is_anim ( mlt_property self )

Check if a property is animated.

This is not a thread-safe function because it is used internally by mlt_property_s under a lock. However, external callers should protect it.

Parameters

self	a property

Returns: true if the property is animated

◆ mlt_property_is_clear()

int mlt_property_is_clear ( mlt_property self )

Check if a property is cleared.

Parameters

self	a property

Returns: true if a property is clear. false if it has been set.

◆ mlt_property_is_color()

int mlt_property_is_color ( mlt_property self )

Check if a property is a color.

Parameters

self	a property

Returns: true if the property is color

◆ mlt_property_is_numeric()

int mlt_property_is_numeric	(	mlt_property	self,
		mlt_locale_t	locale
	)

Determine if the property holds a numeric or numeric string value.

Parameters

self	a property
locale	the locale to use for string evaluation

Returns: true if it is numeric

◆ mlt_property_is_rect()

int mlt_property_is_rect ( mlt_property self )

Check if a property is a rect.

Parameters

self	a property

Returns: true if the property is a rect

◆ mlt_property_pass()

void mlt_property_pass	(	mlt_property	self,
		mlt_property	that
	)

Copy a property.

A Property holding binary data only copies the data if a serialiser function was supplied when you set the Property.

Author: Zach zacha.nosp@m.ry.d.nosp@m.rew@g.nosp@m.mail.nosp@m..com

Parameters

self	a property
that	another property

◆ mlt_property_set_color()

int mlt_property_set_color	(	mlt_property	self,
		mlt_color	value
	)

Set the property to a color value.

Parameters

self	a property
value	an integer

Returns: false

◆ mlt_property_set_data()

int mlt_property_set_data	(	mlt_property	self,
		void *	value,
		int	length,
		mlt_destructor	destructor,
		mlt_serialiser	serialiser
	)

Set a property to an opaque binary value.

This does not make a copy of the data. You can use a Properties object with its reference tracking and the destructor function to control the lifetime of the data. Otherwise, pass NULL for the destructor function and control the lifetime yourself.

Parameters

self	a property
value	an opaque pointer
length	the number of bytes pointed to by value (optional)
destructor	a function to use to destroy this binary data (optional, assuming you manage the resource)
serialiser	a function to use to convert this binary data to a string (optional)

Returns: false

◆ mlt_property_set_double()

int mlt_property_set_double	(	mlt_property	self,
		double	value
	)

Set the property to a floating point value.

Parameters

self	a property
value	a double precision floating point value

Returns: false

◆ mlt_property_set_int()

int mlt_property_set_int	(	mlt_property	self,
		int	value
	)

Set the property to an integer value.

Parameters

self	a property
value	an integer

Returns: false

◆ mlt_property_set_int64()

int mlt_property_set_int64	(	mlt_property	self,
		int64_t	value
	)

Set the property to a 64-bit integer value.

Parameters

self	a property
value	a 64-bit integer

Returns: false

◆ mlt_property_set_position()

int mlt_property_set_position	(	mlt_property	self,
		mlt_position	value
	)

Set the property to a position value.

Position is a relative time value in frame units.

Parameters

self	a property
value	a position value

Returns: false

◆ mlt_property_set_properties()

int mlt_property_set_properties	(	mlt_property	self,
		mlt_properties	properties
	)

Set a nested properties object.

Parameters

self	a property
properties	the properties list to nest into `self` with `name`

Returns: true if error

◆ mlt_property_set_rect()

int mlt_property_set_rect	(	mlt_property	self,
		mlt_rect	value
	)

Set a property to a mlt_rect rectangle.

Parameters

self	a property
value	a rectangle

Returns: false

◆ mlt_property_set_string()

int mlt_property_set_string	(	mlt_property	self,
		const char *	value
	)

Set the property to a string value.

This makes a copy of the string you supply so you do not need to track a new reference to it.

Parameters

self	a property
value	the string to copy to the property

Returns: true if it failed

◆ refresh_animation()

static void refresh_animation	(	mlt_property	self,
		double	fps,
		mlt_locale_t	locale,
		int	length
	)

private

Create a new animation or refresh an existing one.

Parameters

self	a property
fps	the frame rate, which may be needed for converting a time string to frame units
locale	the locale, which may be needed for converting a string to a real number
length	the maximum number of frames when interpreting negative keyframe times, <=0 if you don't care or need that

◆ serialise_mlt_rect()

static char * serialise_mlt_rect	(	mlt_rect *	rect,
		int	length
	)

private

Convert a rectangle value into a string.

The canonical form of a mlt_rect is a space delimited "x y w h o" even though many kinds of field delimiters may be used to convert a string to a rectangle.

Parameters

rect	the rectangle to convert
length	not used

Returns: the string representation of a rectangle

◆ time_clock_from_frames()

static void time_clock_from_frames	(	int	frames,
		double	fps,
		char *	s
	)

private

Convert frame count to a SMIL clock value string.

Parameters

	frames	a frame count
	fps	frames per second
[out]	s	the string to write into - must have enough space to hold largest time string

◆ time_clock_to_frames()

static int time_clock_to_frames	(	mlt_property	self,
		const char *	s,
		double	fps,
		mlt_locale_t	locale
	)

private

Parse a SMIL clock value.

Parameters

self	a property
s	the string to parse
fps	frames per second
locale	the locale to use for parsing a real number value

Returns: position in frames

◆ time_code_to_frames()

static int time_code_to_frames	(	mlt_property	self,
		const char *	s,
		double	fps
	)

private

Parse a SMPTE timecode string.

Parameters

self	a property
s	the string to parse
fps	frames per second

Returns: position in frames

◆ time_smpte_from_frames()

static void time_smpte_from_frames	(	int	frames,
		double	fps,
		char *	s,
		int	drop
	)

private

Convert frame count to a SMPTE timecode string.

Parameters

	frames	a frame count
	fps	frames per second
[out]	s	the string to write into - must have enough space to hold largest time string

Field Documentation

◆ animation

mlt_animation mlt_property_s::animation

◆ data

void* mlt_property_s::data

Generic type handling.

◆ destructor

mlt_destructor mlt_property_s::destructor

◆ length

int mlt_property_s::length

◆ mutex

pthread_mutex_t mlt_property_s::mutex

◆ prop_double

double mlt_property_s::prop_double

◆ prop_int

int mlt_property_s::prop_int

Atomic type handling.

◆ prop_int64

int64_t mlt_property_s::prop_int64

◆ prop_position

mlt_position mlt_property_s::prop_position

◆ prop_string

char* mlt_property_s::prop_string

String handling.

◆ properties

mlt_properties mlt_property_s::properties

◆ serialiser

mlt_serialiser mlt_property_s::serialiser

◆ types

mlt_property_type mlt_property_s::types

Stores a bit pattern of types available for this property.

The documentation for this struct was generated from the following file:

mlt_property.c

Public Member Functions

Data Fields

Private Member Functions

Detailed Description

Member Function Documentation

◆ catmull_rom_interpolate()

◆ clear_property()

◆ linear_interpolate()

◆ mlt_property_anim_get_color()

◆ mlt_property_anim_get_double()

◆ mlt_property_anim_get_int()

◆ mlt_property_anim_get_rect()

◆ mlt_property_anim_get_string()

◆ mlt_property_anim_set_color()

◆ mlt_property_anim_set_double()

◆ mlt_property_anim_set_int()

◆ mlt_property_anim_set_rect()

◆ mlt_property_anim_set_string()

◆ mlt_property_atof()

◆ mlt_property_atoi()

◆ mlt_property_atoll()

◆ mlt_property_clear()

◆ mlt_property_close()

◆ mlt_property_get_animation()

◆ mlt_property_get_color()

◆ mlt_property_get_data()

◆ mlt_property_get_double()

◆ mlt_property_get_int()

◆ mlt_property_get_int64()

◆ mlt_property_get_position()

◆ mlt_property_get_properties()

◆ mlt_property_get_rect()

◆ mlt_property_get_string()

◆ mlt_property_get_string_l()

◆ mlt_property_get_string_l_tf()

◆ mlt_property_get_string_tf()

◆ mlt_property_get_time()

◆ mlt_property_init()

◆ mlt_property_interpolate()

◆ mlt_property_is_anim()

◆ mlt_property_is_clear()

◆ mlt_property_is_color()

◆ mlt_property_is_numeric()

◆ mlt_property_is_rect()

◆ mlt_property_pass()

◆ mlt_property_set_color()

◆ mlt_property_set_data()

◆ mlt_property_set_double()

◆ mlt_property_set_int()

◆ mlt_property_set_int64()

◆ mlt_property_set_position()

◆ mlt_property_set_properties()

◆ mlt_property_set_rect()

◆ mlt_property_set_string()

◆ refresh_animation()

◆ serialise_mlt_rect()

◆ time_clock_from_frames()

◆ time_clock_to_frames()

◆ time_code_to_frames()

◆ time_smpte_from_frames()

Field Documentation

◆ animation

◆ data

◆ destructor

◆ length

◆ mutex

◆ prop_double

◆ prop_int

◆ prop_int64

◆ prop_position

◆ prop_string

◆ properties

◆ serialiser

◆ types
