the factory method interfaces More...

#include "mlt_export.h"
#include "mlt_profile.h"
#include "mlt_repository.h"
#include "mlt_types.h"

Data Structures
struct	mlt_factory_event_data
	The event data for all factory-related events. More...

Functions
MLT_EXPORT char *	mlt_environment (const char *name)
	Get a value from the environment. More...

MLT_EXPORT int	mlt_environment_set (const char name, const char value)
	Set a value in the environment. More...

MLT_EXPORT void	mlt_factory_close ()
	Close the factory. More...

MLT_EXPORT mlt_consumer	mlt_factory_consumer (mlt_profile profile, const char service, const void input)
	Fetch a consumer from the repository. More...

MLT_EXPORT const char *	mlt_factory_directory ()
	Fetch the module directory used in this instance. More...

MLT_EXPORT mlt_properties	mlt_factory_event_object ()
	Fetch the events object. More...

MLT_EXPORT mlt_filter	mlt_factory_filter (mlt_profile profile, const char service, const void input)
	Fetch a filter from the repository. More...

MLT_EXPORT mlt_repository	mlt_factory_init (const char *directory)
	Construct the repository and factories. More...

MLT_EXPORT mlt_link	mlt_factory_link (const char service, const void input)
	Fetch a link from the repository. More...

MLT_EXPORT mlt_producer	mlt_factory_producer (mlt_profile profile, const char service, const void resource)
	Fetch a producer from the repository. More...

MLT_EXPORT void	mlt_factory_register_for_clean_up (void *ptr, mlt_destructor destructor)
	Register an object for clean up. More...

MLT_EXPORT mlt_repository	mlt_factory_repository ()
	Fetch the repository. More...

MLT_EXPORT mlt_transition	mlt_factory_transition (mlt_profile profile, const char service, const void input)
	Fetch a transition from the repository. More...

MLT_EXPORT mlt_properties	mlt_global_properties ()

Detailed Description

the factory method interfaces

This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version 2.1 of the License, or (at your option) any later version.

This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA

Function Documentation

◆ mlt_environment()

MLT_EXPORT char* mlt_environment ( const char * name )

Get a value from the environment.

Parameters

name	the name of a MLT (runtime configuration) environment variable

Returns: the value of the variable

◆ mlt_environment_set()

MLT_EXPORT int mlt_environment_set	(	const char *	name,
		const char *	value
	)

Set a value in the environment.

Parameters

name	the name of a MLT environment variable
value	the value of the variable

Returns: true on error

◆ mlt_factory_close()

MLT_EXPORT void mlt_factory_close ( )

Close the factory.

Cleanup all resources for the session.

◆ mlt_factory_consumer()

MLT_EXPORT mlt_consumer mlt_factory_consumer	(	mlt_profile	profile,
		const char *	service,
		const void *	input
	)

Fetch a consumer from the repository.

Parameters

profile	the `mlt_profile` to use
service	the name of the consumer (optional, defaults to MLT_CONSUMER)
input	an optional argument to the consumer constructor, typically a string

Returns: a new consumer

◆ mlt_factory_directory()

MLT_EXPORT const char* mlt_factory_directory ( )

Fetch the module directory used in this instance.

Returns: the full path to the module directory that this session is using

◆ mlt_factory_event_object()

MLT_EXPORT mlt_properties mlt_factory_event_object ( )

Fetch the events object.

Returns: the global factory event object

◆ mlt_factory_filter()

MLT_EXPORT mlt_filter mlt_factory_filter	(	mlt_profile	profile,
		const char *	service,
		const void *	input
	)

Fetch a filter from the repository.

Parameters

profile	the `mlt_profile` to use
service	the name of the filter
input	an optional argument to the filter constructor, typically a string

Returns: a new filter

◆ mlt_factory_init()

MLT_EXPORT mlt_repository mlt_factory_init ( const char * directory )

Construct the repository and factories.

Environment Variable:

MLT_PRODUCER the name of a default producer often used by other services, defaults to "loader"

MLT_CONSUMER the name of a default consumer, defaults to "sdl2" followed by "sdl"

MLT_TEST_CARD the name of a producer or file to be played when nothing is available (all tracks blank)

MLT_DATA overrides the default full path to the MLT and module supplemental data files, defaults to PREFIX_DATA

MLT_PROFILE selects the default mlt_profile_s, defaults to "dv_pal"

MLT_REPOSITORY overrides the default location of the plugin modules, defaults to PREFIX_LIB.

MLT_REPOSITORY is ignored on Windows and OS X relocatable builds.

Environment Variable:

MLT_PRESETS_PATH overrides the default full path to the properties preset files, defaults to MLT_DATA/presets

MLT_REPOSITORY_DENY colon separated list of modules to skip. Example: libmltplus:libmltavformat:libmltfrei0r In case both qt5 and qt6 modules are found and none of both is blocked by MLT_REPOSITORY_DENY, qt6 will be blocked

Event:

producer-create-request fired when mlt_factory_producer is called; the event data is a pointer to mlt_factory_event_data

producer-create-done fired when a producer registers itself; the event data is a pointer to mlt_factory_event_data

filter-create-request fired when mlt_factory_filter is called; the event data is a pointer to mlt_factory_event_data

filter-create-done fired when a filter registers itself; the event data is a pointer to mlt_factory_event_data

transition-create-request fired when mlt_factory_transition is called; the event data is a pointer to mlt_factory_event_data

transition-create-done fired when a transition registers itself; the event data is a pointer to mlt_factory_event_data

consumer-create-request fired when mlt_factory_consumer is called; the event data is a pointer to mlt_factory_event_data

consumer-create-done fired when a consumer registers itself; the event data is a pointer to mlt_factory_event_data

link-create-request fired when mlt_factory_link is called; the event data is a pointer to mlt_factory_event_data

link-create-done fired when a link registers itself; the event data is a pointer to mlt_factory_event_data

Parameters

directory an optional full path to a directory containing the modules that overrides the default and the MLT_REPOSITORY environment variable

Returns: the repository

◆ mlt_factory_link()

MLT_EXPORT mlt_link mlt_factory_link	(	const char *	service,
		const void *	input
	)

Fetch a link from the repository.

Parameters

service	the name of the link
input	an optional argument to the link constructor, typically a string

Returns: a new link

◆ mlt_factory_producer()

MLT_EXPORT mlt_producer mlt_factory_producer	(	mlt_profile	profile,
		const char *	service,
		const void *	resource
	)

Fetch a producer from the repository.

If you give NULL to service, then it will use core module's special "loader"producer to load resource. One can override this default producer by setting the environment variable MLT_PRODUCER.

Parameters

profile	the `mlt_profile` to use
service	the name of the producer (optional, defaults to MLT_PRODUCER)
resource	an optional argument to the producer constructor, typically a string

Returns: a new producer

◆ mlt_factory_register_for_clean_up()

MLT_EXPORT void mlt_factory_register_for_clean_up	(	void *	ptr,
		mlt_destructor	destructor
	)

Register an object for clean up.

Parameters

ptr	an opaque pointer to anything allocated on the heap
destructor	the function pointer of the deallocation subroutine (e.g., free or `mlt_pool_release`)

◆ mlt_factory_repository()

MLT_EXPORT mlt_repository mlt_factory_repository ( )

Fetch the repository.

Returns: the global repository object

◆ mlt_factory_transition()

MLT_EXPORT mlt_transition mlt_factory_transition	(	mlt_profile	profile,
		const char *	service,
		const void *	input
	)

Fetch a transition from the repository.

Parameters

profile	the `mlt_profile` to use
service	the name of the transition
input	an optional argument to the transition constructor, typically a string

Returns: a new transition

◆ mlt_global_properties()

MLT_EXPORT mlt_properties mlt_global_properties ( )
